Frequently Asked Questions (FAQ)

Q1: What is the primary function of the DO620 module?
A1: It outputs digital (ON/OFF) signals to control field devices such as relays, lights, and actuators.

Q2: How many output channels does the module support?
A2: It supports 16 individual digital output channels.

Q3: What type of output signal does it use?
A3: It provides 24V DC sourcing outputs (positive logic).

Q4: Is the DO620 protected against short circuits?
A4: Yes, the module includes short-circuit and overload protection.

Q5: What ABB system is the DO620 compatible with?
A5: It is fully compatible with ABB’s AC 800M and S800 I/O platforms.

Q6: How is channel status indicated?
A6: Each channel has a dedicated LED for output status and diagnostics.

Q7: Can the module be hot-swapped?
A7: Yes, it supports hot swapping without system shutdown, when installed in the appropriate rack configuration.

Q8: What is the physical size of the DO620?
A8: It measures 252 × 273 × 40 mm.

Q9: What is the operating temperature range of this module?
A9: It operates reliably between -25°C and +70°C.

Q10: What is the total weight of the module?
A10: The DO620 weighs approximately 1.2 kg.
