❓ 10 FAQ (Q&A Format)

Q1: What does the 330850-50-05 module do?
A1: It converts the signal from a proximity probe into a voltage signal proportional to shaft displacement for use in monitoring systems.

Q2: Is it compatible with all 3300 XL probes?
A2: It is specifically designed for use with 3300 XL 25mm proximity probes.

Q3: What is the power supply requirement?
A3: The module requires a power input between –17.5 VDC and –26 VDC.

Q4: What is the total system length for this model?
A4: The system length is 5.0 meters, including the probe, extension cable, and proximitor.

Q5: Can this module be mounted on a DIN rail?
A5: No, this model is intended for panel mounting. DIN-mount versions are available separately.

Q6: Is recalibration needed when replacing the proximitor?
A6: No, components in the 3300 XL series are fully interchangeable without the need for recalibration.

Q7: Does the unit have EMI/RFI immunity?
A7: Yes, it has high immunity against electromagnetic and radio-frequency interference.

Q8: Can it withstand harsh environmental conditions?
A8: Yes, with an IP67 rating and wide temperature range, it is designed for tough industrial settings.

Q9: What is the output signal range?
A9: The voltage output is linear, typically 200 mV/mil or 7.87 mV/µm, depending on configuration.

Q10: What are the dimensions and weight of this module?
A10: It measures approximately 203 × 25 × 35 mm and weighs around 0.10 kg.
