FAQ

Q1: What is the DC input range for the 133292‑01?
A1: It accepts 20–30 V DC input to power the rack.

Q2: How much output current can it deliver?
A2: Up to approximately 11 A to feed the rack modules.

Q3: Does it support hot-swapping?
A3: Yes—if a redundant module is present, it can be swapped without powering down the rack.

Q4: How does redundancy work?
A4: Two modules can be installed—one acts as primary, the other as backup for seamless switchover.

Q5: What diagnostics does it include?
A5: LEDs indicate power presence and fault conditions.

Q6: What protections are built-in?
A6: It includes safeguards against overvoltage, undervoltage, overcurrent, and short circuits.

Q7: What environmental conditions can it handle?
A7: Operating: –30 °C to +65 °C; Storage: –40 °C to +85 °C; Humidity: up to 95% non-condensing.

Q8: What is the module’s size and weight?
A8: 120.7 × 50.8 × 251.5 mm; weight ~1.39 kg.

Q9: What rack position does it occupy?
A9: Two adjacent half-height slots on the left side of the 3500 rack.

Q10: Which applications are best for this module?
A10: It’s ideal for sites with DC power infrastructure and where continuous uptime is critical.
