FAQ – Frequently Asked Questions

Q1: What signals does the module process?
A1: It processes input from proximity probes, magnetic pickups, or optical encoders to generate phase-reference pulses.

Q2: How accurate is the phase reference output?
A2: It provides phase accuracy of ±0.5° at 1× RPM.

Q3: Can it support redundant sensors?
A3: Yes, dual-sensor redundancy with voting logic is supported.

Q4: Is pulse width adjustable?
A4: Yes, configurable from 5° to 330°.

Q5: How does it resist electrical interference?
A5: It includes low-pass and 50/60 Hz notch filters for noise suppression.

Q6: Does the module require shutdown for servicing?
A6: No, it is hot-swappable to allow live replacement.

Q7: Is it suitable for extreme temperatures?
A7: Yes, it operates reliably between –40 °C and +85 °C.

Q8: What certifications does it hold?
A8: It is compliant with SIL 2, API 670, and hazardous-area standards.

Q9: What are its dimensions and weight?
A9: Measures 206 × 32 × 190 mm and weighs 0.34 kg.

Q10: What is its typical power consumption?
A10: Approximately 2.5 W at 24 VDC.
