FAQ (Frequently Asked Questions)

Q1: What is the relay contact rating of the 3500/33 184631-01?

A1: The relay contacts are rated for 5 A at 30 V DC and 2 A at 230 V AC.

Q2: How many relay channels does the module have?

A2: It has 16 independent relay output channels.

Q3: What are the module’s physical dimensions and weight?

A3: Dimensions are 241 mm x 24.4 mm x 242 mm, and it weighs approximately 0.75 kg.

Q4: What operating temperature range is supported?

A4: The module operates reliably between -40°C and +85°C.

Q5: Is the module compatible with other 3500 Series modules?

A5: Yes, it is fully compatible with the entire 3500 Series system.

Q6: What type of relay is used in this module?

A6: The module uses SPDT (Single Pole Double Throw) relays.

Q7: What is the expected relay life?

A7: The relays are rated for over 150,000 switching cycles.

Q8: Does the module support diagnostics?

A8: Yes, it supports relay coil health and contact status diagnostics.

Q9: What industries commonly use this relay output module?

A9: It is widely used in power generation, oil and gas, chemical processing, manufacturing, and marine industries.

Q10: Can the module operate in hazardous environments?

A10: The 184631-01 is not explosion-proof; explosion-proof variants exist within the 3500/33 family for hazardous environments.
