Frequently Asked Questions (QA)

Q1: What functions does this module provide?
A1: Simultaneous vibration and shaft position monitoring across four configurable channels.

Q2: Which sensors can be connected?
A2: Proximity probes, accelerometers, and velocity transducers.

Q3: What are the typical measurement ranges?
A3: Displacement ±25 mm, velocity 0–50 mm/s, acceleration 0–500 m/s², position 0–25 mm.

Q4: How wide is the frequency response?
A4: From 0.1 Hz up to 10 kHz.

Q5: Can alarms be customized per channel?
A5: Yes—each channel has separate alert/danger thresholds.

Q6: What type of output interface is used?
A6: Outputs transmitted via the 3500 backplane to communication modules.

Q7: How much power does it consume?
A7: Typically 9 W, up to 12 W at peak.

Q8: What are its physical dimensions and weight?
A8: 266 × 72 × 229 mm; weighs approximately 0.2 kg.

Q9: What environments can it endure?
A9: Operates reliably between 0 °C and +60 °C in industrial settings.

Q10: Is it compatible with diagnostics software?
A10: Yes—it integrates seamlessly with System 1® through data communication modules.
