Q1: What type of CPU is used in the IC693CPU374 module?
A1: The IC693CPU374 features an embedded high-speed CPU capable of executing user logic with up to 0.15 milliseconds per 1K of Boolean logic, making it suitable for time-critical industrial automation tasks.
Q2: How much user memory is available on this module?
A2: The CPU374 provides 240K bytes of user logic memory and 240K bytes of data memory, which is sufficient for medium-to-large scale applications.
Q3: What kind of programming software is used to configure IC693CPU374?
A3: This module is configured using GE’s Proficy Machine Edition (PME) programming software, which supports ladder diagram, structured text, and function block programming.
Q4: Does the IC693CPU374 support Ethernet communications?
A4: Yes, it comes with a built-in Ethernet interface that supports SRTP (Service Request Transfer Protocol) and Modbus TCP/IP, allowing integration with SCADA and HMI systems.
Q5: Can this CPU be used in a redundant system setup?
A5: No, the IC693CPU374 is not designed for redundancy. If you require redundancy, GE RX3i or RX7i platforms are better suited for those applications.
Q6: How many discrete and analog I/O modules can this CPU control?
A6: The IC693CPU374 can support up to 8 racks with up to 128 I/O modules total, depending on the I/O count per module and system power supply capacity.
Q7: What protocols are supported for networking?
A7: Supported protocols include Ethernet Global Data (EGD), SRTP over Ethernet, and Modbus TCP. It also supports SNP/SNPX over serial connections.
Q8: Does this module support real-time clock functionality?
A8: Yes, the IC693CPU374 includes a real-time clock for time-stamped data logging and event tracking. The clock retains its settings with a battery backup.
Q9: What kind of applications is the IC693CPU374 best suited for?
A9: It is ideal for manufacturing automation, packaging lines, material handling systems, and other process control applications where reliability and fast execution are critical.
Q10: What is the installation footprint of the IC693CPU374?
A10: The module fits into a single slot of a Series 90-30 baseplate and has a compact size of 130 x 33 x 119 mm, with a weight of 0.41kg, making it space-efficient for tight control cabinets.
