❓ Frequently Asked Questions (FAQ)

Q1: How many relay outputs does the CC‑TD0R01 provide?
A1: It provides 8 relay channels.

Q2: What is the maximum current capacity per relay?
A2: Each relay contact can switch up to 5 A at 250 VAC or 30 VDC.

Q3: What coil voltage does this module require?
A3: The relay coils are driven by 24 VDC nominal.

Q4: What protections are built into each channel?
A4: Coil suppression, contact arcing protection, and diagnostic detection of coil or contact faults.

Q5: Can it be used for AC loads?
A5: Yes, the relays can switch AC loads (e.g. motors, heaters) within their rating.

Q6: What is the isolation rating?
A6: 1500 V isolation between relay contacts and internal electronics.

Q7: What are its physical dimensions and weight?
A7: Approx. 120 × 85 × 45 mm, weighing around 0.40 kg.

Q8: What is the operating temperature range?
A8: From –20 °C to +70 °C under normal conditions.

Q9: Is this module suitable for high switching frequency?
A9: The relay design is better for moderate switching; extremely high-frequency switching may reduce relay life.

Q10: Can it integrate with digital I/O modules?
A10: Yes, it often pairs with digital input modules and other I/O devices in modular control systems.
