❓ FAQ (Frequently Asked Questions)

Q1: What is the primary use of the FC-TERM-0002?
A1: It is used to terminate and route analog input signals from field devices to the controller while providing electrical isolation and signal integrity.

Q2: How many analog channels does this module support?
A2: It supports 8 dedicated analog input channels, each capable of handling current or voltage signals.

Q3: Does the module support shielded cables?
A3: Yes, it has terminals for shield grounding, making it suitable for sensitive analog signal applications.

Q4: Is the module suitable for both voltage and current analog inputs?
A4: Yes, each channel can be configured for 0-10V, 4-20mA, or 0-20mA analog signals.

Q5: What kind of terminal blocks are used?
A5: The module comes with screw clamp terminals by default, with optional support for spring clamp connectors.

Q6: Can this module be installed on a DIN rail?
A6: Yes, it is designed for standard DIN rail mounting inside industrial control cabinets.

Q7: What type of systems is it compatible with?
A7: It is compatible with DCS, PLCs, and remote I/O modules that require analog signal interface.

Q8: Does it include LED indicators?
A8: Yes, each analog input channel features an LED for signal status and diagnostic purposes.

Q9: What is the maximum isolation voltage between channels?
A9: The module provides 500V RMS isolation for added safety and noise protection.

Q10: What environments can it operate in?
A10: It operates within -20°C to +60°C and up to 95% non-condensing humidity, making it suitable for industrial environments.
