❓ FAQ (Frequently Asked Questions, QA Format)

Q1: What is the main function of the FC‑TSA0‑0220M?
A1: It converts temperature sensor signals (thermocouples or RTDs) into standard analog output signals while providing conditioning and isolation.

Q2: What sensor types does it support?
A2: It supports common thermocouples (J, K, T, E, R, S) and RTDs (Pt100, Pt1000).

Q3: What is its output signal type?
A3: It outputs 4–20 mA or 0–20 mA, selectable by configuration.

Q4: What level of isolation does it provide?
A4: It provides 1000 V DC isolation between sensor input, output loop, and power.

Q5: What are the module’s dimensions and weight?
A5: It measures 110 mm × 35 mm × 90 mm and weighs about 0.28 kg.

Q6: What is its operational temperature range?
A6: It can operate from –40°C to +85°C.

Q7: Does it have diagnostic capabilities?
A7: Yes, it includes an LED indicator to signal sensor faults or loop integrity issues.

Q8: What is its response time and accuracy?
A8: Response time is under 200 ms, and accuracy is ±0.1% of the chosen span.

Q9: How is it mounted or installed?
A9: It can be mounted on DIN rails or fitted in field housings (if rated for IP65 deployment).

Q10: How is it configured?
A10: Configuration is done via DIP switches or an external configuration tool.
