Frequently Asked Questions (FAQ)

Q1: What is the maximum current each output channel can handle?

A1: Each output channel can handle up to 550 mA.

Q2: What is the operating temperature range of the FS-DO-1224?

A2: The module operates within a temperature range of -40°C to +85°C.

Q3: How many output channels does the FS-DO-1224 have?

A3: The module provides 12 output channels, organized into two groups of 6.

Q4: What is the voltage drop at 500 mA?

A4: The voltage drop is less than 1.5 V DC at 500 mA.

Q5: What is the off current for each output channel?

A5: The off current is less than 0.1 mA.

Q6: Does the FS-DO-1224 have watchdog functionality?

A6: Yes, the module includes a watchdog input current of 0.06 mA.

Q7: What are the power requirements for the FS-DO-1224?

A7: The module requires 5 V DC at 25 mA and 24 V DC at 2 × 30 mA (without output load).

Q8: Is the FS-DO-1224 compatible with industrial automation systems?

A8: Yes, it is designed specifically for industrial automation and process control systems.

Q9: Does this product have any safety or quality certifications?

A9: It meets CE, TUV, UL, and CSA certification standards.

Q10: How much power does the module consume during operation?

A10: Without load, it consumes 25 mA at 5 V DC and 2 × 30 mA at 24 V DC.
