Frequently Asked Questions (FAQ)

Q1: What voltage does the MC-TDIY22 accept?
A1: It accepts a 24 V DC nominal input signal on each channel.

Q2: How many channels are available?
A2: The module provides 16 discrete input channels.

Q3: Can it detect input wiring faults?
A3: Yes, optical isolation and channel-level diagnostics help identify faults.

Q4: What is the module’s response time?
A4: The typical response time is ≤ 5 ms per channel.

Q5: How are status indications provided?
A5: Each channel has a dedicated LED showing ON/OFF state.

Q6: What mounting options exist?
A6: It supports DIN rail mounting or direct panel mounting.

Q7: What are the dimensions and weight?
A7: 160 × 100 × 30 mm; weight is 0.308 kg.

Q8: What operating temperature range does it cover?
A8: –20 °C to +60 °C for reliable industrial use.

Q9: Is the module CE and UL certified?
A9: Yes, it carries CE, UL, and RoHS certifications.

Q10: Which systems is it compatible with?
A10: It integrates seamlessly into Honeywell Experion® PK and ControlEdge™ PK I/O racks.
