9. Frequently Asked Questions (FAQ)

Q1: What is the main purpose of the OVATION 1C31116G04?
A: The 1C31116G04 is designed to capture low-level voltage analog signals from field sensors and convert them into digital data for a control system.

Q2: How many analog channels does this module support?
A: It supports 16 input channels, enabling simultaneous measurement of multiple sensor outputs.

Q3: What are the physical dimensions of this module?
A: The approximate size is 2.5 cm × 8.3 cm × 12.1 cm, allowing compact installation in control racks.

Q4: What is the weight of this module in kilograms?
A: The module weighs approximately 0.10 kg, making it lightweight and easy to handle.

Q5: What type of signals can the 1C31116G04 measure?
A: It measures low-level voltage analog signals, typically in millivolt ranges.

Q6: What is the resolution of the analog-to-digital converter?
A: The module uses a 16-bit ADC, providing fine measurement resolution.

Q7: What operating temperature range is supported?
A: It is rated to operate between –10°C and +60°C.

Q8: What type of power supply does the module require?
A: It requires a 24 V DC power supply, standard for industrial I/O modules.

Q9: Can this module work with other I/O cards in the rack?
A: Yes, it is designed to integrate seamlessly with other OVATION I/O modules on the same backplane.

Q10: Is this module suitable for process control applications?
A: Yes, its precise low-level voltage measurement capability makes it suitable for sensitive process monitoring and control needs.
