Frequently Asked Questions (FAQ)

Q1: What are the physical dimensions and weight of the TSX3710101?
A1: The dimensions are 282.7 x 151 x 152 mm, and it weighs approximately 1.91 kg.

Q2: How many digital inputs and outputs does the TSX3710101 have onboard?
A2: It has 24 digital inputs and 16 relay outputs integrated onboard.

Q3: What types of power supply can the TSX3710101 accept?
A3: The controller supports power supply input ranges of 100–240 V DC or 90–264 V AC.

Q4: Which programming languages are compatible with this controller?
A4: The TSX3710101 supports Ladder Logic, Instruction List, and Structured Text programming languages.

Q5: Can I expand the I/O of the TSX3710101?
A5: Yes, it is compatible with all Modicon TSX Micro 37 series expansion modules for increased I/O.

Q6: What is the typical operating temperature range for this controller?
A6: It operates within a temperature range of 0 °C to +55 °C.

Q7: What communication protocols does it support?
A7: It communicates via the TSX backplane using Modbus-compatible protocol.

Q8: Is the TSX3710101 certified for industrial use?
A8: Yes, it has CE, UL, CSA certifications and complies with RoHS standards.

Q9: How is the TSX3710101 mounted in control panels?
A9: The controller can be mounted on DIN rails or standard rack systems.

Q10: Where can I obtain programming and configuration software?
A10: Schneider Electric provides programming tools such as Unity Pro and SoMachine compatible with this product.
