FAQ (10 Q&A)

Q1: What signals does the AAI143 accept?
A1: It accepts 4–20 mA analog input signals across 16 isolated channels.

Q2: Does it support digital communication?
A2: Yes, H variants support HART digital communication alongside analog signal.

Q3: Can I use it with 2‑wire or 4‑wire transmitters?
A3: Yes—each channel is configurable via dedicated pins.

Q4: What is the module’s accuracy?
A4: Its input accuracy is approximately ±16 μA.

Q5: How quickly does it read data?
A5: It updates all channels every 10 ms.

Q6: How is signal isolation handled?
A6: The module provides full isolation between inputs and system side, rated to 1,500 VAC for 1 minute.

Q7: Is it rugged enough for high-temperature environments?
A7: The S53 and H53 variants operate reliably from –20 °C to +70 °C.

Q8: How much does it weigh?
A8: Approximately 0.30 kg—lightweight and easy to mount.

Q9: What wiring options are available?
A9: Use pressure clamp terminals, MIL connector cables, or dedicated cables for connection.

Q10: Is HART supported on all models?
A10: Only H variants (e.g., H50, H53) support HART communication.
