Frequently Asked Questions (FAQ)

Q1: What do the suffix codes “-H03” and “/K4A00” indicate?
A1: “-H03” denotes HART enabled plus G3 rating (wide temp). “/K4A00” adds a KS cable interface adapter for terminal block compatibility.

Q2: How many channels does the module support and are they isolated?
A2: It supports 16 fully isolated analog input channels.

Q3: Does it support HART communication on every channel?
A3: Yes, HART is fully integrated across all input channels.

Q4: What temperature range is supported?
A4: The G3 option allows operation from –20 °C to +70 °C.

Q5: What isolation strength does the module provide?
A5: It withstands 1,500 VAC between input and system for one minute.

Q6: How accurate are the input measurements?
A6: Accuracy is ±16 µA.

Q7: How quickly does it update channel readings?
A7: Approximately every 10 ms per channel.

Q8: Can transmitter wiring be configured per channel?
A8: Yes—each channel supports either 2‑wire or 4‑wire transmitters via pin setting.

Q9: What is the module’s weight?
A9: It weighs approximately 0.30 kg.

Q10: What connection interface does it use?
A10: It uses a KS cable interface adapter compatible with AEA4D terminal boards.
