FAQ for Yokogawa AAR145-S50:

Q1: What types of sensors are compatible with the AAR145-S50?

A1: The AAR145-S50 supports RTDs (PT100, PT1000) and potentiometers, providing flexibility in measurement applications.

Q2: How many input channels does the AAR145-S50 support?

A2: It supports 16 input channels, allowing for simultaneous measurement of multiple sensors.

Q3: What is the input range for RTDs on the AAR145-S50?

A3: The RTD input range is from -200°C to +850°C for PT100 and PT1000 sensors.

Q4: Is the AAR145-S50 suitable for industrial environments?

A4: Yes, the module is designed for industrial environments and offers high isolation to protect against electrical noise and ground loops.

Q5: What is the power supply requirement for the AAR145-S50?

A5: The module requires a 24 VDC ± 10% power supply.

Q6: What is the operating temperature range of the AAR145-S50?

A6: The module operates within a temperature range of -20°C to +60°C.

Q7: What are the dimensions of the AAR145-S50?

A7: The dimensions of the module are 130 x 127.2 x 32.8 mm.

Q8: Can the AAR145-S50 be used in a multi-sensor environment?

A8: Yes, the AAR145-S50 supports up to 16 sensors, making it ideal for multi-sensor industrial applications.

Q9: Is the AAR145-S50 easy to integrate into existing systems?

A9: Yes, the module is designed to be easily integrated into existing systems with minimal installation effort.

Q10: How much does the AAR145-S50 weigh?

A10: The module weighs 0.3 kg.
