FAQ – 10 Questions

Q1: How many channels does ADV561-P00 provide?
A1: 64 discrete output channels.

Q2: What is the rated output voltage?
A2: 24 V DC.

Q3: What type of outputs does it use?
A3: Current-sink transistor outputs.

Q4: Maximum load current per channel?
A4: 100 mA per channel.

Q5: Does it support pulse-width or time-proportioning output?
A5: Yes, both are supported.

Q6: What is the output response time?
A6: ≤ 3 ms for status; ≤ 10 ms for mixed pulse/time-proportioning.

Q7: How isolated are the outputs?
A7: 2 kV AC between output and system; 500 V AC between commons.

Q8: Weight of the module?
A8: Approximately 0.30 kg.

Q9: How is the module wired?
A9: Via dedicated cables or MIL connector.

Q10: Where is this module ideal?
A10: Large-scale control systems, distributed control systems, or safety-critical applications.
