FAQ – 10 Questions (Q/A)

Q1: How many outputs does the ADV561-P01 support?
A1: It supports 64 independent digital output channels.

Q2: What is the operating voltage?
A2: Nominal 24 V DC; external power range 20.4–26.4 V DC.

Q3: What types of output modes are available?
A3: Pulse-width, time-proportional, and status outputs.

Q4: What is the maximum load per channel?
A4: Each channel can handle 100 mA maximum.

Q5: How fast is the output response?
A5: Status output ≤ 3 ms; pulse-width/time-proportional ≤ 10 ms.

Q6: What is the isolation level?
A6: ~2 kV AC between outputs and system; ~500 V AC between 16-channel groups.

Q7: What are the module’s dimensions and weight?
A7: Approx. 144 mm × 100 mm × 30 mm; weight ~0.31 kg.

Q8: Can it operate in high-temperature environments?
A8: Yes, operational range is -10°C to 65°C.

Q9: Does it support redundancy?
A9: Yes, it can be installed in dual-redundant configurations.

Q10: What applications are best suited?
A10: Large-scale process control, water treatment, power generation, industrial automation, and high-density output control.
