FAQs (10 QA) for VE4002S1T1B2

Q1: How many output channels does VE4002S1T1B2 support?
A1: It supports 8 discrete output channels.

Q2: What is the output voltage and current rating?
A2: The module outputs 24 V DC, with up to 1.0 A per channel.

Q3: Is the output isolated?
A3: Yes — each channel is optically isolated, typically tested to around 1500 V DC.

Q4: What is the leakage current when output is off?
A4: The off‑state leakage is rated at ≤ 1.2 mA.

Q5: What are the supported output modes?
A5: The module supports discrete, momentary pulses, and continuous pulses with configurable timing.

Q6: What is the operating temperature range?
A6: It operates from –40 °C to +70 °C.

Q7: What is the typical weight and dimensions?
A7: Weight is about 0.20 kg; dimensions are approximately 107 × 41 × 105 mm (HxWxD).

Q8: How is the module mounted?
A8: It mounts into a standard I/O carrier or backplane and uses keyed terminal blocks for correct alignment.

Q9: What protection or fault tolerance features exist?
A9: Channels are isolated; the module is designed for robustness (shock, vibration); mis‑wiring prevention is aided by keying.

Q10: Can this module handle pulsed output for timing applications?
A10: Yes — it supports momentary and continuous pulses, with configurable durations and repetition, suited for pulse control tasks.
